command.c File Reference

#include <limits.h>
#include "command.h"
#include "device.h"
#include "devnode.h"
#include "led.h"
#include "notify.h"
#include "profile.h"
#include "usb.h"

Include dependency graph for command.c:

Go to the source code of this file.

Macros
#define	TRY_WITH_RESET(action)

Functions
int	readcmd (usbdevice *kb, const char *line)

Variables
static const char *const	cmd_strings [(CMD_LAST-CMD_FIRST+2)-1]

Macro Definition Documentation

#define TRY_WITH_RESET

(

action

)

Value:

while(action){              \
        if(usb_tryreset(kb)){   \
            free(word);         \
            return 1;           \
        }                       \
    }

Definition at line 59 of file command.c.

Referenced by readcmd().

Function Documentation

int readcmd	(	usbdevice *	kb,
		const char *	line
	)

< Because length of word is length of line + 1, there should be no problem with buffer overflow.

Definition at line 68 of file command.c.

References ACCEL, ACTIVE, usbdevice::active, BIND, CMD_COUNT, CMD_FIRST, cmd_strings, usbprofile::currentmode, DELAY, usbdevice::delay, DITHER, usbdevice::dither, devcmd::do_cmd, devcmd::do_io, devcmd::do_macro, DPI, DPISEL, ERASE, ERASEPROFILE, FEAT_ANSI, FEAT_BIND, FEAT_ISO, FEAT_LMASK, FEAT_MOUSEACCEL, FEAT_NOTIFY, usbdevice::features, lighting::forceupdate, FPS, FWUPDATE, GET, HAS_FEATURES, HWLOAD, HWSAVE, IAUTO, ID, IDLE, INDEX_OF, INOTIFY, IOFF, ION, IS_FULLRANGE, IS_MOUSE_DEV, keymap, LAYOUT, left, LIFT, usbmode::light, MACRO, mknotifynode(), MODE, usbprofile::mode, MODE_COUNT, N_KEYS_EXTENDED, NAME, NEEDS_FW_UPDATE, NONE, NOTIFY, NOTIFYOFF, NOTIFYON, OUTFIFO_MAX, POLLRATE, usbdevice::profile, PROFILEID, PROFILENAME, REBIND, RESTART, RGB, right(), rmnotifynode(), SCROLL_ACCELERATED, SCROLL_MAX, SCROLL_MIN, SCROLLSPEED, SNAP, SWITCH, TRY_WITH_RESET, UNBIND, usbdevice::usbdelay, and usbdevice::vtable.

Referenced by devmain().

                                            {
    char* word = malloc(strlen(line) + 1);
    int wordlen;
    const char* newline = 0;
    const devcmd* vt = kb->vtable;
    usbprofile* profile = kb->profile;
    usbmode* mode = 0;
    int notifynumber = 0;
    // Read words from the input
    cmd command = NONE;
    while(sscanf(line, "%s%n", word, &wordlen) == 1){
        line += wordlen;
        // If we passed a newline, reset the context
        if(line > newline){
            mode = profile->currentmode;
            command = NONE;
            notifynumber = 0;
            newline = strchr(line, '\n');
            if(!newline)
                newline = line + strlen(line);
        }
        // Check for a command word
        for(int i = 0; i < CMD_COUNT - 1; i++){
            if(!strcmp(word, cmd_strings[i])){
                command = i + CMD_FIRST;
#ifndef OS_MAC
                // Layout and mouse acceleration aren't used on Linux; ignore
                if(command == LAYOUT || command == ACCEL || command == SCROLLSPEED)
                    command = NONE;
#endif
                // Most commands require parameters, but a few are actions in and of themselves
                if(command != SWITCH
                        && command != HWLOAD && command != HWSAVE
                        && command != ACTIVE && command != IDLE
                        && command != ERASE && command != ERASEPROFILE
                        && command != RESTART)
                    goto next_loop;
                break;
            }
        }

        // Set current notification node when given @number
        int newnotify;
        if(sscanf(word, "@%u", &newnotify) == 1 && newnotify < OUTFIFO_MAX){
            notifynumber = newnotify;
            continue;
        }

        // Reject unrecognized commands. Reject bind or notify related commands if the keyboard doesn't have the feature enabled.
        if(command == NONE
                || ((!HAS_FEATURES(kb, FEAT_BIND) && (command == BIND || command == UNBIND || command == REBIND || command == MACRO || command == DELAY))
                           || (!HAS_FEATURES(kb, FEAT_NOTIFY) && command == NOTIFY))){
            next_loop:
            continue;
        }
        // Reject anything not related to fwupdate if device has a bricked FW
        if(NEEDS_FW_UPDATE(kb) && command != FWUPDATE && command != NOTIFYON && command != NOTIFYOFF)
            continue;

        // Specially handled commands - these are available even when keyboard is IDLE
        switch(command){
        case NOTIFYON: {
            // Notification node on
            int notify;
            if(sscanf(word, "%u", &notify) == 1)
                mknotifynode(kb, notify);
            continue;
        } case NOTIFYOFF: {
            // Notification node off
            int notify;
            if(sscanf(word, "%u", &notify) == 1 && notify != 0) // notify0 can't be removed
                rmnotifynode(kb, notify);
            continue;
        } case GET:
            // Output data to notification node
            vt->get(kb, mode, notifynumber, 0, word);
            continue;
        case LAYOUT:
            // OSX: switch ANSI/ISO keyboard layout
            if(!strcmp(word, "ansi"))
                kb->features = (kb->features & ~FEAT_LMASK) | FEAT_ANSI;
            else if(!strcmp(word, "iso"))
                kb->features = (kb->features & ~FEAT_LMASK) | FEAT_ISO;
            continue;
#ifdef OS_MAC
        case ACCEL:
            // OSX mouse acceleration on/off
            if(!strcmp(word, "on"))
                kb->features |= FEAT_MOUSEACCEL;
            else if(!strcmp(word, "off"))
                kb->features &= ~FEAT_MOUSEACCEL;
            continue;
        case SCROLLSPEED:{
            int newscroll;
            if(sscanf(word, "%d", &newscroll) != 1)
                break;
            if(newscroll < SCROLL_MIN)
                newscroll = SCROLL_ACCELERATED;
            if(newscroll > SCROLL_MAX)
                newscroll = SCROLL_MAX;
            kb->scroll_rate = newscroll;
            continue;
        }
#endif
        case MODE: {
            // Select a mode number (1 - 6)
            int newmode;
            if(sscanf(word, "%u", &newmode) == 1 && newmode > 0 && newmode <= MODE_COUNT)
                mode = profile->mode + newmode - 1;
            continue;
        }
        case FPS: {
            // USB command delay (2 - 10ms)
            uint framerate;
            if(sscanf(word, "%u", &framerate) == 1 && framerate > 0){
                // Not all devices require the same number of messages per frame; select delay appropriately
                uint per_frame = IS_MOUSE_DEV(kb) ? 2 : IS_FULLRANGE(kb) ? 14 : 5;
                uint delay = 1000 / framerate / per_frame;
                if(delay < 2)
                    delay = 2;
                else if(delay > 10)
                    delay = 10;
                kb->usbdelay = delay;
            }
            continue;
        }
        case DITHER: {
            // 0: No dither, 1: Ordered dither.
            uint dither;
            if(sscanf(word, "%u", &dither) == 1 && dither <= 1){
                kb->dither = dither;
                profile->currentmode->light.forceupdate = 1;
                mode->light.forceupdate = 1;
            }
            continue;
        }
        case DELAY: {
            long int delay;
            if(sscanf(word, "%ld", &delay) == 1 && 0 <= delay && delay < UINT_MAX) {
                // Add delay of `newdelay` microseconds to macro playback
                kb->delay = (unsigned int)delay;
            } else if(strcmp(word, "on") == 0) {
                // allow previous syntax, `delay on` means use old `long macro delay`
                kb->delay = UINT_MAX;
            } else {
                // bad parameter to handle false commands like "delay off"
                kb->delay = 0; // No delay.
            }
            continue;
        }
        case RESTART: {
            char mybuffer[] = "no reason specified";
            if (sscanf(line, " %[^\n]", word) == -1) {
                word = mybuffer;
            }
            vt->do_cmd[command](kb, mode, notifynumber, 0, word);
            continue;
        }
        default:;
        }

        // If a keyboard is inactive, it must be activated before receiving any other commands
        if(!kb->active){
            if(command == ACTIVE)
                TRY_WITH_RESET(vt->active(kb, mode, notifynumber, 0, 0));
            continue;
        }
        // Specially handled commands only available when keyboard is ACTIVE
        switch(command){
        case IDLE:
            TRY_WITH_RESET(vt->idle(kb, mode, notifynumber, 0, 0));
            continue;
        case SWITCH:
            if(profile->currentmode != mode){
                profile->currentmode = mode;
                // Set mode light for non-RGB K95
                int index = INDEX_OF(mode, profile->mode);
                vt->setmodeindex(kb, index);
            }
            continue;
        case HWLOAD: case HWSAVE:{
            char delay = kb->usbdelay;
            // Ensure delay of at least 10ms as the device can get overwhelmed otherwise
            if(delay < 10)
                kb->usbdelay = 10;
            // Try to load/save the hardware profile. Reset on failure, disconnect if reset fails.
            TRY_WITH_RESET(vt->do_io[command](kb, mode, notifynumber, 1, 0));
            // Re-send the current RGB state as it sometimes gets scrambled
            TRY_WITH_RESET(vt->updatergb(kb, 1));
            kb->usbdelay = delay;
            continue;
        }
        case FWUPDATE:
            // FW update parses a whole word. Unlike hwload/hwsave, there's no try again on failure.
            if(vt->fwupdate(kb, mode, notifynumber, 0, word)){
                free(word);
                return 1;
            }
            continue;
        case POLLRATE: {
            uint rate;
            if(sscanf(word, "%u", &rate) == 1 && (rate == 1 || rate == 2 || rate == 4 || rate == 8))
                TRY_WITH_RESET(vt->pollrate(kb, mode, notifynumber, rate, 0));
            continue;
        }
        case ERASEPROFILE:
            // Erase the current profile
            vt->eraseprofile(kb, mode, notifynumber, 0, 0);
            // Update profile/mode pointers
            profile = kb->profile;
            mode = profile->currentmode;
            continue;
        case ERASE: case NAME: case IOFF: case ION: case IAUTO: case INOTIFY: case PROFILENAME: case ID: case PROFILEID: case DPISEL: case LIFT: case SNAP:
            // All of the above just parse the whole word
            vt->do_cmd[command](kb, mode, notifynumber, 0, word);
            continue;
        case RGB: {
            // RGB command has a special response for a single hex constant
            int r, g, b;
            if(sscanf(word, "%02x%02x%02x", &r, &g, &b) == 3){
                // Set all keys
                for(int i = 0; i < N_KEYS_EXTENDED; i++)
                    vt->rgb(kb, mode, notifynumber, i, word);
                continue;
            }
            break;
        }
        case MACRO:
            if(!strcmp(word, "clear")){
                // Macro has a special clear command
                vt->macro(kb, mode, notifynumber, 0, 0);
                continue;
            }
            break;
        default:;
        }
        // For anything else, split the parameter at the colon
        int left = -1;
        sscanf(word, "%*[^:]%n", &left);
        if(left <= 0)
            continue;
        const char* right = word + left;
        if(right[0] == ':')
            right++;
        // Macros and DPI have a separate left-side handler
        if(command == MACRO || command == DPI){
            word[left] = 0;
            vt->do_macro[command](kb, mode, notifynumber, word, right);
            continue;
        }
        // Scan the left side for key names and run the requested command
        int position = 0, field = 0;
        char keyname[11];
        while(position < left && sscanf(word + position, "%10[^:,]%n", keyname, &field) == 1){
            int keycode;
            if(!strcmp(keyname, "all")){
                // Set all keys
                for(int i = 0; i < N_KEYS_EXTENDED; i++)
                    vt->do_cmd[command](kb, mode, notifynumber, i, right);
            } else if((sscanf(keyname, "#%d", &keycode) && keycode >= 0 && keycode < N_KEYS_EXTENDED)
                      || (sscanf(keyname, "#x%x", &keycode) && keycode >= 0 && keycode < N_KEYS_EXTENDED)){
                // Set a key numerically
                vt->do_cmd[command](kb, mode, notifynumber, keycode, right);
            } else {
                // Find this key in the keymap
                for(unsigned i = 0; i < N_KEYS_EXTENDED; i++){
                    if(keymap[i].name && !strcmp(keyname, keymap[i].name)){
                        vt->do_cmd[command](kb, mode, notifynumber, i, right);
                        break;
                    }
                }
            }
            if(word[position += field] == ',')
                position++;
        }
    }

    // Finish up
    if(!NEEDS_FW_UPDATE(kb)){
        TRY_WITH_RESET(vt->updatergb(kb, 0));
        TRY_WITH_RESET(vt->updatedpi(kb, 0));
    }
    free(word);
    return 0;
}

Here is the call graph for this function:

Here is the caller graph for this function:

Variable Documentation

const char* const cmd_strings[(CMD_LAST-CMD_FIRST+2)-1]

static

Definition at line 10 of file command.c.

Referenced by readcmd().
