Key Struct Reference

#include <src/ckb/keymap.h>

Collaboration diagram for Key:

Public Member Functions
const char *	storageName () const
QString	friendlyName (bool os=true) const
	operator bool () const
bool	operator! () const

Data Fields
const char *	_storageName
const char *	_friendlyName
const char *	name
short	x
short	y
short	width
short	height
bool	hasLed
bool	hasScan

Detailed Description

Definition at line 8 of file keymap.h.

Member Function Documentation

QString Key::friendlyName ( bool  os = true ) const

inline

Definition at line 23 of file keymap.h.

References _friendlyName, and name.

Referenced by KbBind::friendlyName(), KeyWidget::mouseMoveEvent(), KeyWidget::paintEvent(), RebindWidget::setBind(), and KbBindWidget::updateSelDisplay().

                                                      {
        if(os){
#ifdef Q_OS_MACX
            if(!strcmp(name, "lwin")) return "Left Cmd";
            if(!strcmp(name, "rwin")) return "Right Cmd";
            if(!strcmp(name, "lalt")) return "Left Option";
            if(!strcmp(name, "ralt")) return "Right Option";
            if(!strcmp(name, "prtscn")) return "F13";
            if(!strcmp(name, "scroll")) return "F14";
            if(!strcmp(name, "pause")) return "F15";
            if(!strcmp(name, "ins")) return "Help";
            if(!strcmp(name, "numlock")) return "Clear";
#elif defined(Q_OS_LINUX)
            if(!strcmp(name, "lwin")) return "Left Super";
            if(!strcmp(name, "rwin")) return "Right Super";
#endif
        }
        return _friendlyName ? _friendlyName : QString(name).toUpper();
    }

Here is the caller graph for this function:

Key::operator bool ( ) const

inline

Definition at line 44 of file keymap.h.

References name.

{ return name != 0; }

bool Key::operator! ( ) const

inline

Definition at line 45 of file keymap.h.

{ return !(bool)*this; }

const char* Key::storageName ( ) const

inline

Definition at line 11 of file keymap.h.

References _storageName, and name.

Referenced by KeyMap::toStorage().

{ return _storageName ? _storageName : name; }

Here is the caller graph for this function:

Field Documentation

const char* Key::_friendlyName

Definition at line 13 of file keymap.h.

Referenced by _patch(), and friendlyName().

const char* Key::_storageName

Definition at line 10 of file keymap.h.

Referenced by _patch(), and storageName().

bool Key::hasLed

Definition at line 19 of file keymap.h.

Referenced by ColorMap::init(), KeyWidget::mouseMoveEvent(), KeyWidget::mousePressEvent(), KeyWidget::paintEvent(), and KeyWidget::selectAll().

bool Key::hasScan

Definition at line 20 of file keymap.h.

Referenced by KeyWidget::mouseMoveEvent(), KeyWidget::mousePressEvent(), KeyWidget::paintEvent(), and KeyWidget::selectAll().

short Key::height

Definition at line 17 of file keymap.h.

Referenced by getMap(), KeyWidget::mouseMoveEvent(), KeyWidget::mousePressEvent(), KeyWidget::paintEvent(), and patchANSI().

const char* Key::name

Definition at line 14 of file keymap.h.

Referenced by friendlyName(), ColorMap::init(), KeyWidget::mouseMoveEvent(), KeyWidget::mousePressEvent(), operator bool(), KeyWidget::paintEvent(), KeyWidget::selectAll(), and storageName().

short Key::width

Definition at line 17 of file keymap.h.

Referenced by getMap(), KeyWidget::mouseMoveEvent(), KeyWidget::mousePressEvent(), KeyWidget::paintEvent(), and patchANSI().

short Key::x

Definition at line 16 of file keymap.h.

Referenced by AnimScript::begin(), KeyMap::byPosition(), getMap(), AnimScript::keypress(), KeyWidget::mouseMoveEvent(), KeyWidget::mousePressEvent(), KeyWidget::paintEvent(), and patchANSI().

short Key::y

Definition at line 16 of file keymap.h.

Referenced by AnimScript::begin(), KeyMap::byPosition(), getMap(), AnimScript::keypress(), KeyWidget::mouseMoveEvent(), KeyWidget::mousePressEvent(), KeyWidget::paintEvent(), and patchANSI().

---

The documentation for this struct was generated from the following file:

• src/ckb/keymap.h
