#include "includes.h"
#include "keymap.h"

Include dependency graph for structures.h:

This graph shows which files directly or indirectly include this file:

Data Structures
struct	usbid

struct	macroaction

struct	keymacro

struct	binding

struct	dpiset

struct	lighting

struct	usbmode

struct	usbprofile

struct	hwprofile

struct	usbinput

struct	usbdevice

Macros
#define	SET_KEYBIT(array, index) do { (array)[(index) / 8] \|= 1 << ((index) % 8); } while(0)

#define	CLEAR_KEYBIT(array, index) do { (array)[(index) / 8] &= ~(1 << ((index) % 8)); } while(0)

#define	I_NUM 1

#define	I_CAPS 2

#define	I_SCROLL 4

#define	OUTFIFO_MAX 10

#define	MACRO_MAX 1024

#define	DPI_COUNT 6

#define	LIFT_MIN 1

#define	LIFT_MAX 5

#define	MD_NAME_LEN 16

#define	PR_NAME_LEN 16

#define	MODE_COUNT 6

#define	HWMODE_K70 1

#define	HWMODE_K95 3

#define	HWMODE_MAX 3

#define	FEAT_RGB 0x001

#define	FEAT_MONOCHROME 0x002

#define	FEAT_POLLRATE 0x004

#define	FEAT_ADJRATE 0x008

#define	FEAT_BIND 0x010

#define	FEAT_NOTIFY 0x020

#define	FEAT_FWVERSION 0x040

#define	FEAT_FWUPDATE 0x080

#define	FEAT_HWLOAD 0x100

#define	FEAT_ANSI 0x200

#define	FEAT_ISO 0x400

#define	FEAT_MOUSEACCEL 0x800

#define	FEAT_COMMON (FEAT_BIND \| FEAT_NOTIFY \| FEAT_FWVERSION \| FEAT_MOUSEACCEL \| FEAT_HWLOAD)

#define	FEAT_STD_RGB (FEAT_COMMON \| FEAT_RGB \| FEAT_POLLRATE \| FEAT_FWUPDATE)

#define	FEAT_STD_NRGB (FEAT_COMMON)

#define	FEAT_LMASK (FEAT_ANSI \| FEAT_ISO)

#define	HAS_FEATURES(kb, feat) (((kb)->features & (feat)) == (feat))

#define	HAS_ANY_FEATURE(kb, feat) (!!((kb)->features & (feat)))

#define	NEEDS_FW_UPDATE(kb) ((kb)->fwversion == 0 && HAS_FEATURES((kb), FEAT_FWUPDATE \| FEAT_FWVERSION))

#define	SCROLL_ACCELERATED 0

#define	SCROLL_MIN 1

#define	SCROLL_MAX 10

#define	KB_NAME_LEN 40

#define	SERIAL_LEN 34

#define	MSG_SIZE 64

#define	IFACE_MAX 4

Variables
const union devcmd	vtable_keyboard
	RGB keyboard vtable holds functions for each device type. More...

const union devcmd	vtable_keyboard_nonrgb

const union devcmd	vtable_mouse

Data Structure Documentation

struct usbid

Definition at line 8 of file structures.h.

Collaboration diagram for usbid:

Data Fields
char	guid[16]
char	modified[4]

struct macroaction

Definition at line 27 of file structures.h.

Collaboration diagram for macroaction:

Data Fields
uint	delay
char	down
short	rel_x
short	rel_y
short	scan

struct keymacro

Definition at line 35 of file structures.h.

Collaboration diagram for keymacro:

Data Fields
int	actioncount
macroaction *	actions
uchar	combo[((((152+3+12)+25)+7)/8)]
char	triggered

struct binding

Definition at line 43 of file structures.h.

Collaboration diagram for binding:

Data Fields
int	base[((152+3+12)+25)]
int	macrocap
int	macrocount
keymacro *	macros

struct dpiset

Definition at line 57 of file structures.h.

Collaboration diagram for dpiset:

Data Fields
uchar	current
uchar	enabled
uchar	forceupdate
uchar	lift
uchar	snap
ushort	x[6]
ushort	y[6]

struct lighting

Definition at line 73 of file structures.h.

Collaboration diagram for lighting:

Data Fields
uchar	b[152+11]
uchar	forceupdate
uchar	g[152+11]
uchar	r[152+11]
uchar	sidelight

struct usbmode

Definition at line 83 of file structures.h.

Collaboration diagram for usbmode:

Data Fields
binding	bind
dpiset	dpi
usbid	id
uchar	inotify[10]
uchar	ioff
uchar	ion
lighting	light
ushort	name[16]
uchar	notify[10][((((152+3+12)+25)+7)/8)]

struct usbprofile

Definition at line 101 of file structures.h.

Collaboration diagram for usbprofile:

Data Fields
usbmode *	currentmode
usbid	id
dpiset	lastdpi
lighting	lastlight
usbmode	mode[6]
ushort	name[16]

struct hwprofile

Definition at line 118 of file structures.h.

Collaboration diagram for hwprofile:

Data Fields
dpiset	dpi[3]
usbid	id[3+1]
lighting	light[3]
ushort	name[3+1][16]

struct usbinput

Definition at line 129 of file structures.h.

Collaboration diagram for usbinput:

Data Fields
uchar	keys[((((152+3+12)+25)+7)/8)]
uchar	prevkeys[((((152+3+12)+25)+7)/8)]
short	rel_x
short	rel_y

struct usbdevice

Definition at line 178 of file structures.h.

Collaboration diagram for usbdevice:

Data Fields
char	active
uint	delay
char	dither
int	epcount
ushort	features
ushort	fwversion
int	handle
hwprofile *	hw
uchar	hw_ileds
uchar	hw_ileds_old
uchar	ileds
int	infifo
usbinput	input
pthread_t	inputthread
char	name[40+1]
int	outfifo[10]
char	pollrate
short	product
usbprofile *	profile
char	serial[34]
pthread_t	thread
struct udev_device *	udev
int	uinput_kb
int	uinput_mouse
char	usbdelay
short	vendor
const union devcmd *	vtable
