#include <ctype.h>
#include <math.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>

Include dependency graph for ckb-anim.h:

Data Structures
struct	ckb_key

struct	ckb_runctx

struct	ckb_gradient

Macros
#define	M_PI 3.14159265358979323846

#define	TRUE 1

#define	FALSE 0

#define	CKB_DOWN 1

#define	CKB_UP 0

#define	CKB_CONTAINER(macro) do { macro } while(0)

#define	CKB_GUID(guid) CKB_CONTAINER( printf("guid "); printurl(guid); printf("\n"); )

#define	CKB_NAME(name) CKB_CONTAINER( printf("name "); printurl(name); printf("\n"); )

#define	CKB_VERSION(version) CKB_CONTAINER( printf("version "); printurl(version); printf("\n"); )

#define	CKB_COPYRIGHT(year, author) CKB_CONTAINER( printf("author "); printurl(author); printf("\nyear %s\n", year); )

#define	CKB_LICENSE(license) CKB_CONTAINER( printf("license "); printurl(license); printf("\n"); )

#define	CKB_DESCRIPTION(description) CKB_CONTAINER( printf("description "); printurl(description); printf("\n"); )

#define	CKB_PARAM(type, name, prefix, postfix, extra) CKB_CONTAINER( printf("param %s %s ", type, name); printurl(prefix); printf(" "); printurl(postfix); printf(" "); extra; printf("\n"); )

#define	CKB_PARAM_LONG(name, prefix, postfix, default, min, max) CKB_PARAM("long", name, prefix, postfix, printf("%ld %ld %ld", (long)(default), (long)(min), (long)(max)))

#define	CKB_PARAM_DOUBLE(name, prefix, postfix, default, min, max) CKB_PARAM("double", name, prefix, postfix, printf("%lf %lf %lf", (double)(default), (double)(min), (double)(max)))

#define	CKB_PARAM_BOOL(name, text, default) CKB_PARAM("bool", name, text, "", printf((default) ? "1" : "0"))

#define	CKB_PARAM_RGB(name, prefix, postfix, r, g, b) CKB_PARAM("rgb", name, prefix, postfix, printf("%02x%02x%02x", (unsigned char)(r), (unsigned char)(g), (unsigned char)(b)))

#define	CKB_PARAM_ARGB(name, prefix, postfix, a, r, g, b) CKB_PARAM("argb", name, prefix, postfix, printf("%02x%02x%02x%02x", (unsigned char)(a), (unsigned char)(r), (unsigned char)(g), (unsigned char)(b)))

#define	CKB_PARAM_GRADIENT(name, prefix, postfix, default) CKB_PARAM("gradient", name, prefix, postfix, printurl(default))

#define	CKB_PARAM_AGRADIENT(name, prefix, postfix, default) CKB_PARAM("agradient", name, prefix, postfix, printurl(default))

#define	CKB_PARAM_ANGLE(name, prefix, postfix, default) CKB_PARAM("angle", name, prefix, postfix, printf("%ld", (long)(default)))

#define	CKB_PARAM_STRING(name, prefix, postfix, default) CKB_PARAM("string", name, prefix, postfix, printurl(default))

#define	CKB_PARAM_LABEL(name, text) CKB_PARAM("label", name, text, "", )

#define	CKB_PRESET_START(name) CKB_CONTAINER( printf("preset "); printurl(name); )

#define	CKB_PRESET_PARAM(name, value) CKB_CONTAINER( printf(" %s=", name); printurl(value); )

#define	CKB_PRESET_END CKB_CONTAINER( printf("\n"); )

#define	CKB_KP_NONE "none"

#define	CKB_KP_NAME "name"

#define	CKB_KP_POSITION "position"

#define	CKB_KPMODE(mode) CKB_CONTAINER( printf("kpmode %s\n", mode); )

#define	CKB_TIME_DURATION "duration"

#define	CKB_TIME_ABSOLUTE "absolute"

#define	CKB_TIMEMODE(mode) CKB_CONTAINER( printf("time %s\n", mode); )

#define	CKB_REPEAT(enable) CKB_CONTAINER( printf("repeat %s\n", (enable) ? "on" : "off"); )

#define	CKB_PREEMPT(enable) CKB_CONTAINER( printf("preempt %s\n", (enable) ? "on" : "off"); )

#define	CKB_LIVEPARAMS(enable) CKB_CONTAINER( printf("parammode %s\n", (enable) ? "live" : "static"); )

#define	CKB_PARSE_LONG(param_name, value_ptr) if(!strcmp(name, param_name) && sscanf(value, "%ld", value_ptr) == 1)

#define	CKB_PARSE_DOUBLE(param_name, value_ptr) if(!strcmp(name, param_name) && sscanf(value, "%lf", value_ptr) == 1)

#define	CKB_PARSE_BOOL(param_name, value_ptr) if(!strcmp(name, param_name) && sscanf(value, "%u", value_ptr) == 1)

#define	CKB_PARSE_RGB(param_name, r_ptr, g_ptr, b_ptr) if(!strcmp(name, param_name) && sscanf(value, "%2hhx%2hhx%2hhx", r_ptr, g_ptr, b_ptr) == 3)

#define	CKB_PARSE_ARGB(param_name, a_ptr, r_ptr, g_ptr, b_ptr) if(!strcmp(name, param_name) && sscanf(value, "%2hhx%2hhx%2hhx%2hhx", a_ptr, r_ptr, g_ptr, b_ptr) == 4)

#define	CKB_PARSE_GRADIENT(param_name, gradient_ptr) if(!strcmp(name, param_name) && ckb_scan_grad(value, gradient_ptr, 0))

#define	CKB_PARSE_AGRADIENT(param_name, gradient_ptr) if(!strcmp(name, param_name) && ckb_scan_grad(value, gradient_ptr, 1))

#define	CKB_PARSE_ANGLE(param_name, value_ptr) if(!strcmp(name, param_name) && sscanf(value, "%ld", value_ptr) == 1)

#define	CKB_PARSE_STRING(param_name) if(!strcmp(name, param_name))

#define	CKB_REAL_ANGLE(angle) fmod((-(angle) + 90.) * M_PI / 180. + M_PI * 2., M_PI * 2.)

#define	CKB_KEYNAME_MAX 12

#define	CKB_KEYCLEAR(context) CKB_CONTAINER( ckb_key* key = context->keys; unsigned count = context->keycount; unsigned i = 0; for(; i < count; i++) key[i].a = key[i].r = key[i].g = key[i].b = 0; )

#define	CKB_GRAD_MAX 100

#define	CKB_MAX_WORD (4 * 1024)

Functions
int	ckb_scan_grad (const char string, ckb_gradient gradient, int alpha)

void	ckb_grad_color (float a, float r, float g, float b, const ckb_gradient *grad, float pos)

void	ckb_alpha_blend (ckb_key *key, float a, float r, float g, float b)

void	printurl (const char *src)

void	urldecode (char dst, const char src)

void	ckb_getline (char word1[(4 1024)], char word2[(4 1024)], char word3[(4 *1024)])

void	ckb_info ()

void	ckb_init (ckb_runctx *context)

void	ckb_parameter (ckb_runctx , const char , const char *)

void	ckb_keypress (ckb_runctx , ckb_key , int, int, int)

void	ckb_start (ckb_runctx *, int)

void	ckb_time (ckb_runctx *, double)

int	ckb_frame (ckb_runctx *)

void	ckb_read_params (ckb_runctx *ctx)

int	main (int argc, char *argv[])

Data Structure Documentation

struct ckb_key

Definition at line 131 of file ckb-anim.h.

Collaboration diagram for ckb_key:

Data Fields
unsigned char	a
unsigned char	b
unsigned char	g
char	name[12]
unsigned char	r
int	x
int	y

struct ckb_runctx

Definition at line 138 of file ckb-anim.h.

Collaboration diagram for ckb_runctx:

Data Fields
unsigned	height
unsigned	keycount
ckb_key *	keys
unsigned	width

struct ckb_gradient

Definition at line 152 of file ckb-anim.h.

Collaboration diagram for ckb_gradient:

Data Fields
unsigned char	a[100]
unsigned char	b[100]
unsigned char	g[100]
int	ptcount
char	pts[100]
unsigned char	r[100]

Macro Definition Documentation

#define CKB_CONTAINER ( macro ) do { macro } while(0)

Definition at line 57 of file ckb-anim.h.

#define CKB_COPYRIGHT	(	year,
		author
	)	CKB_CONTAINER( printf("author "); printurl(author); printf("\nyear %s\n", year); )

Definition at line 66 of file ckb-anim.h.

#define CKB_DESCRIPTION ( description ) CKB_CONTAINER( printf("description "); printurl(description); printf("\n"); )

Definition at line 70 of file ckb-anim.h.

#define CKB_DOWN 1

Definition at line 52 of file ckb-anim.h.

#define CKB_GRAD_MAX 100

Definition at line 151 of file ckb-anim.h.

#define CKB_GUID ( guid ) CKB_CONTAINER( printf("guid "); printurl(guid); printf("\n"); )

Definition at line 60 of file ckb-anim.h.

#define CKB_KEYCLEAR ( context ) CKB_CONTAINER( ckb_key* key = context->keys; unsigned count = context->keycount; unsigned i = 0; for(; i < count; i++) key[i].a = key[i].r = key[i].g = key[i].b = 0; )

Definition at line 148 of file ckb-anim.h.

#define CKB_KEYNAME_MAX 12

Definition at line 130 of file ckb-anim.h.

Referenced by main().

#define CKB_KP_NAME "name"

Definition at line 91 of file ckb-anim.h.

#define CKB_KP_NONE "none"

Definition at line 90 of file ckb-anim.h.

#define CKB_KP_POSITION "position"

Definition at line 92 of file ckb-anim.h.

#define CKB_KPMODE ( mode ) CKB_CONTAINER( printf("kpmode %s\n", mode); )

Definition at line 93 of file ckb-anim.h.

#define CKB_LICENSE ( license ) CKB_CONTAINER( printf("license "); printurl(license); printf("\n"); )

Definition at line 68 of file ckb-anim.h.

#define CKB_LIVEPARAMS ( enable ) CKB_CONTAINER( printf("parammode %s\n", (enable) ? "live" : "static"); )

Definition at line 104 of file ckb-anim.h.

#define CKB_MAX_WORD (4 * 1024)

Definition at line 238 of file ckb-anim.h.

Referenced by ckb_read_params(), and main().

#define CKB_NAME ( name ) CKB_CONTAINER( printf("name "); printurl(name); printf("\n"); )

Definition at line 62 of file ckb-anim.h.

#define CKB_PARAM	(	type,
		name,
		prefix,
		postfix,
		extra
	)	CKB_CONTAINER( printf("param %s %s ", type, name); printurl(prefix); printf(" "); printurl(postfix); printf(" "); extra; printf("\n"); )

Definition at line 73 of file ckb-anim.h.

#define CKB_PARAM_AGRADIENT	(	name,
		prefix,
		postfix,
		default
	)	CKB_PARAM("agradient", name, prefix, postfix, printurl(default))

Definition at line 80 of file ckb-anim.h.

#define CKB_PARAM_ANGLE	(	name,
		prefix,
		postfix,
		default
	)	CKB_PARAM("angle", name, prefix, postfix, printf("%ld", (long)(default)))

Definition at line 81 of file ckb-anim.h.

#define CKB_PARAM_ARGB	(	name,
		prefix,
		postfix,
		a,
		r,
		g,
		b
	)	CKB_PARAM("argb", name, prefix, postfix, printf("%02x%02x%02x%02x", (unsigned char)(a), (unsigned char)(r), (unsigned char)(g), (unsigned char)(b)))

Definition at line 78 of file ckb-anim.h.

#define CKB_PARAM_BOOL	(	name,
		text,
		default
	)	CKB_PARAM("bool", name, text, "", printf((default) ? "1" : "0"))

Definition at line 76 of file ckb-anim.h.

#define CKB_PARAM_DOUBLE	(	name,
		prefix,
		postfix,
		default,
		min,
		max
	)	CKB_PARAM("double", name, prefix, postfix, printf("%lf %lf %lf", (double)(default), (double)(min), (double)(max)))

Definition at line 75 of file ckb-anim.h.

#define CKB_PARAM_GRADIENT	(	name,
		prefix,
		postfix,
		default
	)	CKB_PARAM("gradient", name, prefix, postfix, printurl(default))

Definition at line 79 of file ckb-anim.h.

#define CKB_PARAM_LABEL	(	name,
		text
	)	CKB_PARAM("label", name, text, "", )

Definition at line 83 of file ckb-anim.h.

#define CKB_PARAM_LONG	(	name,
		prefix,
		postfix,
		default,
		min,
		max
	)	CKB_PARAM("long", name, prefix, postfix, printf("%ld %ld %ld", (long)(default), (long)(min), (long)(max)))

Definition at line 74 of file ckb-anim.h.

#define CKB_PARAM_RGB	(	name,
		prefix,
		postfix,
		r,
		g,
		b
	)	CKB_PARAM("rgb", name, prefix, postfix, printf("%02x%02x%02x", (unsigned char)(r), (unsigned char)(g), (unsigned char)(b)))

Definition at line 77 of file ckb-anim.h.

#define CKB_PARAM_STRING	(	name,
		prefix,
		postfix,
		default
	)	CKB_PARAM("string", name, prefix, postfix, printurl(default))

Definition at line 82 of file ckb-anim.h.

#define CKB_PARSE_AGRADIENT	(	param_name,
		gradient_ptr
	)	if(!strcmp(name, param_name) && ckb_scan_grad(value, gradient_ptr, 1))

Definition at line 121 of file ckb-anim.h.

#define CKB_PARSE_ANGLE	(	param_name,
		value_ptr
	)	if(!strcmp(name, param_name) && sscanf(value, "%ld", value_ptr) == 1)

Definition at line 122 of file ckb-anim.h.

#define CKB_PARSE_ARGB	(	param_name,
		a_ptr,
		r_ptr,
		g_ptr,
		b_ptr
	)	if(!strcmp(name, param_name) && sscanf(value, "%2hhx%2hhx%2hhx%2hhx", a_ptr, r_ptr, g_ptr, b_ptr) == 4)

Definition at line 119 of file ckb-anim.h.

#define CKB_PARSE_BOOL	(	param_name,
		value_ptr
	)	if(!strcmp(name, param_name) && sscanf(value, "%u", value_ptr) == 1)

Definition at line 117 of file ckb-anim.h.

#define CKB_PARSE_DOUBLE	(	param_name,
		value_ptr
	)	if(!strcmp(name, param_name) && sscanf(value, "%lf", value_ptr) == 1)

Definition at line 116 of file ckb-anim.h.

#define CKB_PARSE_GRADIENT	(	param_name,
		gradient_ptr
	)	if(!strcmp(name, param_name) && ckb_scan_grad(value, gradient_ptr, 0))

Definition at line 120 of file ckb-anim.h.

#define CKB_PARSE_LONG	(	param_name,
		value_ptr
	)	if(!strcmp(name, param_name) && sscanf(value, "%ld", value_ptr) == 1)

Definition at line 115 of file ckb-anim.h.

#define CKB_PARSE_RGB	(	param_name,
		r_ptr,
		g_ptr,
		b_ptr
	)	if(!strcmp(name, param_name) && sscanf(value, "%2hhx%2hhx%2hhx", r_ptr, g_ptr, b_ptr) == 3)

Definition at line 118 of file ckb-anim.h.

#define CKB_PARSE_STRING ( param_name ) if(!strcmp(name, param_name))

Definition at line 123 of file ckb-anim.h.

#define CKB_PREEMPT ( enable ) CKB_CONTAINER( printf("preempt %s\n", (enable) ? "on" : "off"); )

Definition at line 102 of file ckb-anim.h.

#define CKB_PRESET_END CKB_CONTAINER( printf("\n"); )

Definition at line 87 of file ckb-anim.h.

#define CKB_PRESET_PARAM	(	name,
		value
	)	CKB_CONTAINER( printf(" %s=", name); printurl(value); )

Definition at line 86 of file ckb-anim.h.

#define CKB_PRESET_START ( name ) CKB_CONTAINER( printf("preset "); printurl(name); )

Definition at line 85 of file ckb-anim.h.

#define CKB_REAL_ANGLE ( angle ) fmod((-(angle) + 90.) * M_PI / 180. + M_PI * 2., M_PI * 2.)

Definition at line 127 of file ckb-anim.h.

#define CKB_REPEAT ( enable ) CKB_CONTAINER( printf("repeat %s\n", (enable) ? "on" : "off"); )

Definition at line 99 of file ckb-anim.h.

#define CKB_TIME_ABSOLUTE "absolute"

Definition at line 96 of file ckb-anim.h.

#define CKB_TIME_DURATION "duration"

Definition at line 95 of file ckb-anim.h.

#define CKB_TIMEMODE ( mode ) CKB_CONTAINER( printf("time %s\n", mode); )

Definition at line 97 of file ckb-anim.h.

#define CKB_UP 0

Definition at line 53 of file ckb-anim.h.

#define CKB_VERSION ( version ) CKB_CONTAINER( printf("version "); printurl(version); printf("\n"); )

Definition at line 64 of file ckb-anim.h.

#define FALSE 0

Definition at line 49 of file ckb-anim.h.

#define M_PI 3.14159265358979323846

Definition at line 42 of file ckb-anim.h.

#define TRUE 1

Definition at line 46 of file ckb-anim.h.

Function Documentation

void ckb_alpha_blend	(	ckb_key *	key,
		float	a,
		float	r,
		float	g,
		float	b
	)

Definition at line 283 of file ckb-anim.h.

References ckb_key::a, ckb_key::b, ckb_key::g, and ckb_key::r.

                                                                       {
     a /= 255.f;
     float ka = key->a / 255.f;
     float a2 = a + (1.f - a) * ka;
     if(a2 == 0.f){
         key->a = key->r = key->g = key->b = 0;
         return;
     }
     key->a = round(a2 * 255.f);
     key->r = round((r * a + key->r * ka * (1.f - a)) / a2);
     key->g = round((g * a + key->g * ka * (1.f - a)) / a2);
     key->b = round((b * a + key->b * ka * (1.f - a)) / a2);
 }

int ckb_frame ( ckb_runctx * )

Referenced by main().

Here is the caller graph for this function:

void ckb_getline	(	char	word1[(4 *1024)],
		char	word2[(4 *1024)],
		char	word3[(4 *1024)]
	)

Definition at line 239 of file ckb-anim.h.

References urldecode().

Referenced by ckb_read_params(), and main().

                                                                                               {
     char line[CKB_MAX_WORD * 3 + 3];
     fgets(line, sizeof(line), stdin);
     word1[0] = word1[1] = word1[2] = 0;
     int res = sscanf(line, "%s %s %s", word1, word2, word3);
     if(res >= 1)
         urldecode(word1, word1);
     if(res >= 2)
         urldecode(word2, word2);
     if(res >= 3)
         urldecode(word3, word3);
     line[strlen(line) - 1] = 0;
 }

Here is the call graph for this function:

Here is the caller graph for this function:

void ckb_grad_color	(	float *	a,
		float *	r,
		float *	g,
		float *	b,
		const ckb_gradient *	grad,
		float	pos
	)

Definition at line 254 of file ckb-anim.h.

References ckb_gradient::a, ckb_gradient::b, ckb_gradient::g, ckb_gradient::ptcount, ckb_gradient::pts, and ckb_gradient::r.

                                                                                                 {
     // Find the points surrounding this position
     int count = grad->ptcount;
     if(count == 0){
         *a = *r = *g = *b = 0.f;
         return;
     }
     int i = 1;
     for(; i < count; i++){
         if(grad->pts[i] >= pos)
             break;
     }
     // Get color by linear interpolation. Premultiply the alpha value so that it returns the expected color
     // (i.e. stops with zero opacity won't contribute to color)
     float distance = grad->pts[i] - grad->pts[i - 1];
     float dx = (pos - grad->pts[i - 1]) / distance;
     float a1 = grad->a[i] / 255., a2 = grad->a[i - 1] / 255.;
     float a3 = *a = a1 * dx + a2 * (1.f - dx);
     if(a3 == 0.){
         *a = *r = *g = *b = 0.f;
         return;
     }
     *a *= 255.f;
     *r = (grad->r[i] * a1 * dx + grad->r[i - 1] * a2 * (1.f - dx)) / a3;
     *g = (grad->g[i] * a1 * dx + grad->g[i - 1] * a2 * (1.f - dx)) / a3;
     *b = (grad->b[i] * a1 * dx + grad->b[i - 1] * a2 * (1.f - dx)) / a3;
 }

void ckb_info ( )

Referenced by main().

Here is the caller graph for this function:

void ckb_init ( ckb_runctx * context )

Referenced by main().

Here is the caller graph for this function:

void ckb_keypress	(	ckb_runctx *	,
		ckb_key *	,
		int	,
		int	,
		int
	)

Referenced by main().

Here is the caller graph for this function:

void ckb_parameter	(	ckb_runctx *	,
		const char *	,
		const char *
	)

Referenced by ckb_read_params().

Here is the caller graph for this function:

void ckb_read_params ( ckb_runctx * ctx )

Definition at line 349 of file ckb-anim.h.

References ckb_getline(), CKB_MAX_WORD, and ckb_parameter().

Referenced by main().

                                      {
     char cmd[CKB_MAX_WORD], param[CKB_MAX_WORD], value[CKB_MAX_WORD];
     do {
         ckb_getline(cmd, param, value);
         if(!*cmd){
             printf("Error [ckb-main]: Reached EOF reading parameters");
             return;
         }
         if(!strcmp(cmd, "end") && !strcmp(param, "params"))
             break;
         if(strcmp(cmd, "param"))
             continue;
         ckb_parameter(ctx, param, value);
     } while(1);
 }

Here is the call graph for this function:

Here is the caller graph for this function:

int ckb_scan_grad	(	const char *	string,
		ckb_gradient *	gradient,
		int	alpha
	)

Definition at line 298 of file ckb-anim.h.

References ckb_gradient::a, ckb_gradient::b, ckb_gradient::g, ckb_gradient::ptcount, ckb_gradient::pts, and ckb_gradient::r.

                                                                         {
     char pos = -1;
     unsigned char a = 255, r, g, b;
     int count = 0;
     while(1){
         int scanned = 0;
         char newpos;
         if(sscanf(string, "%hhd:%2hhx%2hhx%2hhx%2hhx%n", &newpos, &a, &r, &g, &b, &scanned) != 5)
             break;
         string += scanned;
         // Don't allow stops out-of-order or past 100
         if(newpos <= pos || newpos > 100)
             return 0;
         pos = newpos;
         if(!alpha)
             a = 255;
         gradient->pts[count] = pos;
         gradient->a[count] = a;
         gradient->r[count] = r;
         gradient->g[count] = g;
         gradient->b[count] = b;
         count++;
     }
     if(count == 0){
         // If nothing was read, try a single ARGB constant.
         if(sscanf(string, "%2hhx%2hhx%2hhx%2hhx", &a, &r, &g, &b) != 4)
             return 0;
         count = 2;
         gradient->pts[0] = 0;
         gradient->pts[1] = 100;
         gradient->a[0] = a;
         gradient->a[1] = 0;
         gradient->r[0] = gradient->r[1] = r;
         gradient->g[0] = gradient->g[1] = g;
         gradient->b[0] = gradient->b[1] = b;
     }
     if(count < 2)
         return 0;
     gradient->ptcount = count;
     return 1;
 }

void ckb_start	(	ckb_runctx *	,
		int
	)

Referenced by main().

Here is the caller graph for this function:

void ckb_time	(	ckb_runctx *	,
		double
	)

Referenced by main().

Here is the caller graph for this function:

int main	(	int	argc,
		char *	argv[]
	)

Definition at line 365 of file ckb-anim.h.

References ckb_key::a, ckb_key::b, ckb_frame(), ckb_getline(), ckb_info(), ckb_init(), CKB_KEYNAME_MAX, ckb_keypress(), CKB_MAX_WORD, ckb_read_params(), ckb_start(), ckb_time(), ckb_key::g, ckb_runctx::height, ckb_runctx::keycount, ckb_runctx::keys, ckb_key::name, ckb_key::r, ckb_runctx::width, ckb_key::x, and ckb_key::y.

                                 {
     if(argc == 2){
         if(!strcmp(argv[1], "--ckb-info")){
             ckb_info();
             fflush(stdout);
             return 0;
         } else if(!strcmp(argv[1], "--ckb-run")){
             ckb_runctx ctx;
             // Read the keymap lines
             char cmd[CKB_MAX_WORD], param[CKB_MAX_WORD], value[CKB_MAX_WORD];
             // Skip anything up until "begin keymap"
             do {
                 ckb_getline(cmd, param, value);
                 if(!*cmd){
                     // If end-of-file is reached, abort
                     printf("Error [ckb-main]: Reached EOF looking for \"begin keymap\"");
                     return -2;
                 }
             } while(strcmp(cmd, "begin") || strcmp(param, "keymap"));
             ckb_getline(cmd, param, value);
             unsigned keycount;
             if(strcmp(cmd, "keycount") || sscanf(param, "%u", &keycount) != 1 || keycount == 0){
                 // If keycount isn't the next line, something is wrong
                 printf("Error [ckb-main]: \"begin keymap\" not followed with \"keycount\"");
                 return -3;
             }
             ctx.keys = (ckb_key*)calloc(keycount, sizeof(ckb_key));
             ctx.keycount = keycount;
             unsigned max_x = 0, max_y = 0;
             unsigned i = 0;
             for(; i < ctx.keycount; i++){
                 ckb_getline(cmd, param, value);
                 unsigned x, y;
                 if(strcmp(cmd, "key") || !*param || !sscanf(value, "%u,%u", &x, &y)){
                     i--;
                     continue;
                 }
                 ckb_key* key = ctx.keys + i;
                 strncpy(key->name, param, CKB_KEYNAME_MAX);
                 key->x = x;
                 key->y = y;
                 if(x > max_x)
                     max_x = x;
                 if(y > max_y)
                     max_y = y;
             }
             ctx.width = max_x + 1;
             ctx.height = max_y + 1;
             // Skip anything else until "end keymap"
             do {
                 ckb_getline(cmd, param, value);
                 if(!*cmd){
                     printf("Error [ckb-main]: Reached EOF looking for \"end keymap\"");
                     return -2;
                 }
             } while(strcmp(cmd, "end") || strcmp(param, "keymap"));
             // Run init function
             ckb_init(&ctx);
             // Skip anything else until "begin params"
             do {
                 ckb_getline(cmd, param, value);
                 if(!*cmd){
                     printf("Error [ckb-main]: Reached EOF looking for \"begin params\"");
                     return -2;
                 }
             } while(strcmp(cmd, "begin") || strcmp(param, "params"));
             // Parse parameters
             ckb_read_params(&ctx);
             // Skip anything else until "begin run"
             do {
                 ckb_getline(cmd, param, value);
                 if(!*cmd){
                     printf("Error [ckb-main]: Reached EOF looking for \"begin run\"");
                     return -2;
                 }
             } while(strcmp(cmd, "begin") || strcmp(param, "run"));
             // Run the main loop
             printf("begin run\n");
             fflush(stdout);
             while(1){
                 ckb_getline(cmd, param, value);
                 if(!*cmd || (!strcmp(cmd, "end") && !strcmp(param, "run")))
                     break;
                 // Parse input
                 if(!strcmp(cmd, "start"))
                     ckb_start(&ctx, 1);
                 else if(!strcmp(cmd, "stop"))
                     ckb_start(&ctx, 0);
                 else if(!strcmp(cmd, "begin") && !strcmp(param, "params"))
                     ckb_read_params(&ctx);
                 else if(!strcmp(cmd, "key")){
                     int x, y;
                     if(sscanf(param, "%d,%d", &x, &y) == 2){
                         // Find a key with this position
                         ckb_key* key = 0;
                         for(i = 0; i < keycount; i++){
                             if(ctx.keys[i].x == x && ctx.keys[i].y == y){
                                 key = ctx.keys + i;
                                 break;
                             }
                         }
                         if(key)
                             ckb_keypress(&ctx, key, key->x, key->y, !strcmp(value, "down"));
                         else
                             ckb_keypress(&ctx, 0, x, y, !strcmp(value, "down"));
                     } else {
                         // Find a key with this name
                         ckb_key* key = 0;
                         for(i = 0; i < keycount; i++){
                             if(!strcmp(ctx.keys[i].name, param)){
                                 key = ctx.keys + i;
                                 break;
                             }
                         }
                         if(key)
                             ckb_keypress(&ctx, key, key->x, key->y, !strcmp(value, "down"));
                     }
                 } else if(!strcmp(cmd, "frame")){
                     int end = ckb_frame(&ctx);
                     // Output the frame
                     printf("begin frame\n");
                     for(i = 0; i < ctx.keycount; i++){
                         ckb_key* key = ctx.keys + i;
                         printf("argb %s %02hhx%02hhx%02hhx%02hhx\n", key->name, key->a, key->r, key->g, key->b);
                     }
                     printf("end frame\n");
                     if(end)
                         break;
                     fflush(stdout);
                 } else {
                     double delta = 0.;
                     if(!strcmp(cmd, "time") && sscanf(param, "%lf", &delta) == 1)
                         ckb_time(&ctx, delta);
                 }
             }
             printf("end run\n");
             fflush(stdout);
             free(ctx.keys);
             return 0;
         }
     }
     printf("This program must be run from within ckb\n");
     return -1;
 }

Here is the call graph for this function:

void printurl ( const char * src )

Definition at line 178 of file ckb-anim.h.

                               {
     char out[strlen(src) * 3 + 1];
     char* dst = out;
     char s;
     while((s = *src++)){
         if(s <= ',' || s == '/' ||
                 (s >= ':' && s <= '@') ||
                 s == '[' || s == ']' ||
                 s >= 0x7F){
             char a = s >> 4, b = s & 0xF;
             if(a >= 10)
                 a += 'A' - 10;
             else
                 a += '0';
             if(b >= 10)
                 b += 'A' - 10;
             else
                 b += '0';
             dst[0] = '%';
             dst[1] = a;
             dst[2] = b;
             dst += 3;
         } else
             *dst++ = s;
     }
     *dst = '\0';
     printf("%s", out);
 }

void urldecode	(	char *	dst,
		const char *	src
	)

Definition at line 208 of file ckb-anim.h.

Referenced by ckb_getline().

                                           {
     char a, b;
     char s;
     while((s = *src)){
         if((s == '%') &&
                 ((a = src[1]) && (b = src[2])) &&
                 (isxdigit(a) && isxdigit(b))){
             if(a >= 'a')
                 a -= 'a'-'A';
             if(a >= 'A')
                 a -= 'A' - 10;
             else
                 a -= '0';
             if(b >= 'a')
                 b -= 'a'-'A';
             if(b >= 'A')
                 b -= 'A' - 10;
             else
                 b -= '0';
             *dst++ = 16*a + b;
             src += 3;
         } else {
             *dst++ = s;
             src++;
         }
     }
     *dst = '\0';
 }

Here is the caller graph for this function:

Data Structures

Macros

Functions

Data Structure Documentation

Macro Definition Documentation

Function Documentation
