KeyMap Class Reference

#include <src/ckb/keymap.h>

Collaboration diagram for KeyMap:

Public Types
enum	Model {   NO_MODEL = -1, K65, K70, K95,   STRAFE, M65, SABRE, SCIMITAR,   _MODEL_MAX }
enum	Layout {   NO_LAYOUT = -1, DK, EU, EU_DVORAK,   GB, GB_DVORAK, US, US_DVORAK,   FR, DE, IT, NO,   PL, MX, ES, SE,   _LAYOUT_MAX }

Public Member Functions
bool	isISO () const
bool	isKeyboard () const
bool	isMouse () const
	KeyMap ()
	KeyMap (Model _keyModel, Layout _keyLayout)
QString	strLayout () const
QString	strModel () const
Model	model () const
Layout	layout () const
QString	name () const
uint	count () const
uint	width () const
uint	height () const
Key	key (const QString &name) const
Key	operator[] (const QString &name) const
bool	contains (const QString &name) const
const QHash< QString, Key > &	map () const
	operator const QHash< QString, Key > & () const
QStringList	keys () const
QList< Key >	positions () const
QString	toStorage (const QString &name)
QString	fromStorage (const QString &storage)
QStringList	byPosition () const

Static Public Member Functions
static QStringList	layoutNames ()
static bool	isISO (Layout layout)
static Layout	locale ()
static bool	isKeyboard (Model model)
static bool	isMouse (Model model)
static KeyMap	fromName (const QString &name)
static Layout	getLayout (const QString &name)
static QString	getLayout (Layout layout)
static Model	getModel (const QString &name)
static QString	getModel (Model model)
static QString	friendlyName (const QString &key, Layout layout=US)

Static Private Member Functions
static int	modelWidth (Model model)
static int	modelHeight (Model model)

Private Attributes
QHash< QString, Key >	_keys
short	keyWidth
short	keyHeight
Model	keyModel:8
Layout	keyLayout:8

Detailed Description

Definition at line 49 of file keymap.h.

Member Enumeration Documentation

enum KeyMap::Layout

Enumerator
NO_LAYOUT
DK
EU
EU_DVORAK
GB
GB_DVORAK
US
US_DVORAK
FR
DE
IT
NO
PL
MX
ES
SE
_LAYOUT_MAX

Definition at line 65 of file keymap.h.

                {
        NO_LAYOUT = -1,
        DK,                 // Danish
        EU,                 // English (EU)
        EU_DVORAK,
        GB,                 // English (UK)
        GB_DVORAK,
        US,                 // English (US)
        US_DVORAK,
        FR,                 // French
        DE,                 // German
        IT,                 // Italian
        NO,                 // Norwegian
        PL,                 // Polish (identical to US)
        MX,                 // Spanish (Mexico/Latin America)
        ES,                 // Spanish (Spain)
        SE,                 // Swedish
        _LAYOUT_MAX
    };

enum KeyMap::Model

Enumerator
NO_MODEL
K65
K70
K95
STRAFE
M65
SABRE
SCIMITAR
_MODEL_MAX

Definition at line 51 of file keymap.h.

               {
        NO_MODEL = -1,
        // Keyboard models
        K65,
        K70,
        K95,
        STRAFE,
        // Mouse models
        M65,
        SABRE,
        SCIMITAR,
        _MODEL_MAX
    };

Constructor & Destructor Documentation

KeyMap::KeyMap

(

)

Definition at line 583 of file keymap.cpp.

Referenced by friendlyName(), and fromName().

               :
     keyWidth(0), keyHeight(0),
     keyModel(NO_MODEL), keyLayout(NO_LAYOUT)
{}

Here is the caller graph for this function:

KeyMap::KeyMap	(	Model	_keyModel,
		Layout	_keyLayout
	)

Definition at line 577 of file keymap.cpp.

                                                 :
    _keys(getMap(_keyModel, _keyLayout)),
    keyWidth(modelWidth(_keyModel)), keyHeight(modelHeight(_keyModel)),
    keyModel(_keyModel), keyLayout(_keyLayout)
{}

Member Function Documentation

QStringList KeyMap::byPosition

(

)

const

Definition at line 588 of file keymap.cpp.

References key(), Key::x, and Key::y.

Referenced by RebindWidget::setBind().

                                     {
    // Use QMaps to order the keys
    QMap<int, QMap<int, QString> > ordered;
    QHashIterator<QString, Key> i(*this);
    while(i.hasNext()){
        i.next();
        const Key& key = i.value();
        ordered[key.y][key.x] = i.key();
    }
    // Merge them into a single list
    QStringList result;
    QMapIterator<int, QMap<int, QString> > y(ordered);
    while(y.hasNext()){
        y.next();
        QMapIterator<int, QString> x(y.value());
        while(x.hasNext()){
            x.next();
            result << x.value();
        }
    }
    return result;
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool KeyMap::contains ( const QString &  name ) const

inline

Definition at line 127 of file keymap.h.

References _keys.

Referenced by friendlyName(), and KbAnimWidget::on_keyButton_clicked().

{ return _keys.contains(name); }

Here is the caller graph for this function:

uint KeyMap::count ( ) const

inline

Definition at line 118 of file keymap.h.

References _keys.

Referenced by KeyWidget::map(), KbBindWidget::on_copyButton_clicked(), and KbBindWidget::on_resetButton_clicked().

{ return _keys.count(); }

Here is the caller graph for this function:

QString KeyMap::friendlyName ( const QString &  key, Layout  layout = US  )

static

Definition at line 611 of file keymap.cpp.

References contains(), K95, KeyMap(), M65, map(), SCIMITAR, and STRAFE.

Referenced by KeyAction::friendlyName(), and RebindWidget::RebindWidget().

                                                             {
    // Try K95 map first
    // FIXME: This is an odd function and probably should be refactored
    // it would probably be best to remove the friendly names from the maps and have a completely separate name->friendlyName store
    KeyMap map(K95, layout);
    if(map.contains(key))
        return map[key].friendlyName();

    // The only key missing from it should be Fn, which is found on STRAFE
    map = KeyMap(STRAFE, layout);
    if(map.contains(key))
        return map[key].friendlyName();

    // Additionally, there are a handful of keys not present on any physical keyboard, but we need names for them
    if(key == "f13" || key == "f14" || key == "f15" || key == "f16" || key == "f17" || key == "f18" || key == "f19" || key == "f20")
        return key.toUpper();
    else if(key == "lightup")
        return "Screen Brightness Up";
    else if(key == "lightdn")
        return "Screen Brightness Down";
    else if(key == "eject" || key == "power")
        return key[0].toUpper() + key.mid(1);   // capitalize first letter

    // All other names are found on mice
    map = KeyMap(SCIMITAR, layout);
    if(map.contains(key))
        return map[key].friendlyName();
    map = KeyMap(M65, layout);
    if(map.contains(key))
        return map[key].friendlyName();

    // Not found at all
    return "";
}

Here is the call graph for this function:

Here is the caller graph for this function:

KeyMap KeyMap::fromName ( const QString &  name )

static

Definition at line 535 of file keymap.cpp.

References getLayout(), getModel(), and KeyMap().

Referenced by KbBind::load(), and KbLight::load().

                                          {
    QStringList list = name.trimmed().split(" ");
    if(list.length() != 2)
        return KeyMap();
    return KeyMap(getModel(list[0]), getLayout(list[1]));
}

Here is the call graph for this function:

Here is the caller graph for this function:

QString KeyMap::fromStorage ( const QString &  storage )

inline

Definition at line 135 of file keymap.h.

Referenced by KbAnim::KbAnim(), KbBind::load(), and KbLight::load().

{ QHashIterator<QString, Key> i(*this); while(i.hasNext()) { i.next(); const char* s = i.value().storageName(); if(s == storage) return i.value().name; } return storage; }

Here is the caller graph for this function:

KeyMap::Layout KeyMap::getLayout ( const QString &  name )

static

Definition at line 407 of file keymap.cpp.

References DE, DK, ES, EU, EU_DVORAK, FR, GB, GB_DVORAK, IT, MX, NO, NO_LAYOUT, PL, SE, US, and US_DVORAK.

Referenced by fromName(), SettingsWidget::on_layoutBox_activated(), SettingsWidget::SettingsWidget(), and strLayout().

                                                 {
    QString lower = name.toLower();
    if(lower == "dk")
        return DK;
    if(lower == "eu")
        return EU;
    if(lower == "eu_dvorak")
        return EU_DVORAK;
    if(lower == "gb_dvorak")
        return GB_DVORAK;
    if(lower == "us")
        return US;
    if(lower == "us_dvorak")
        return US_DVORAK;
    if(lower == "fr")
        return FR;
    if(lower == "de")
        return DE;
    if(lower == "it")
        return IT;
    if(lower == "no")
        return NO;
    if(lower == "pl")
        return PL;
    if(lower == "mx")
        return MX;
    if(lower == "es")
        return ES;
    if(lower == "se")
        return SE;
    if(lower == "gb")
        return GB;
    return NO_LAYOUT;
}

Here is the caller graph for this function:

QString KeyMap::getLayout ( KeyMap::Layout  layout )

static

Definition at line 442 of file keymap.cpp.

References DE, DK, ES, EU, EU_DVORAK, FR, GB, GB_DVORAK, IT, MX, NO, PL, SE, US, and US_DVORAK.

                                            {
    switch(layout){
    case DK:
        return "dk";
    case EU:
        return "eu";
    case EU_DVORAK:
        return "eu_dvorak";
    case GB:
        return "gb";
    case GB_DVORAK:
        return "gb_dvorak";
    case US:
        return "us";
    case US_DVORAK:
        return "us_dvorak";
    case FR:
        return "fr";
    case DE:
        return "de";
    case IT:
        return "it";
    case NO:
        return "no";
    case PL:
        return "pl";
    case MX:
        return "mx";
    case ES:
        return "es";
    case SE:
        return "se";
    default:
        return "";
    }
}

KeyMap::Model KeyMap::getModel ( const QString &  name )

static

Definition at line 495 of file keymap.cpp.

References K65, K70, K95, M65, NO_MODEL, SABRE, SCIMITAR, and STRAFE.

Referenced by fromName(), Kb::Kb(), and strModel().

                                               {
    QString lower = name.toLower();
    if(lower == "k65")
        return K65;
    if(lower == "k70")
        return K70;
    if(lower == "k95")
        return K95;
    if(lower == "strafe")
        return STRAFE;
    if(lower == "m65")
        return M65;
    if(lower == "sabre")
        return SABRE;
    if(lower == "scimitar")
        return SCIMITAR;
    return NO_MODEL;
}

Here is the caller graph for this function:

QString KeyMap::getModel ( KeyMap::Model  model )

static

Definition at line 514 of file keymap.cpp.

References K65, K70, K95, M65, SABRE, SCIMITAR, and STRAFE.

                                         {
    switch(model){
    case K65:
        return "k65";
    case K70:
        return "k70";
    case K95:
        return "k95";
    case STRAFE:
        return "strafe";
    case M65:
        return "m65";
    case SABRE:
        return "sabre";
    case SCIMITAR:
        return "scimitar";
    default:
        return "";
    }
}

uint KeyMap::height ( ) const

inline

Definition at line 122 of file keymap.h.

References keyHeight.

Referenced by KeyWidget::drawInfo(), and KeyWidget::map().

{ return keyHeight; }

Here is the caller graph for this function:

static bool KeyMap::isISO ( Layout  layout )

inlinestatic

Definition at line 87 of file keymap.h.

References PL, US, and US_DVORAK.

Referenced by KbBind::isISO(), and RebindWidget::setBind().

{ return layout != US && layout != US_DVORAK && layout != PL; }

Here is the caller graph for this function:

bool KeyMap::isISO ( ) const

inline

Definition at line 88 of file keymap.h.

References isISO(), and keyLayout.

Referenced by getMap(), isISO(), Kb::Kb(), and Kb::updateLayout().

{ return isISO(keyLayout); }

Here is the call graph for this function:

Here is the caller graph for this function:

static bool KeyMap::isKeyboard ( Model  model )

inlinestatic

Definition at line 93 of file keymap.h.

References isMouse(), and NO_MODEL.

Referenced by KbBind::isKeyboard().

{ return !isMouse(model) && model != NO_MODEL; }

Here is the call graph for this function:

Here is the caller graph for this function:

bool KeyMap::isKeyboard ( ) const

inline

Definition at line 94 of file keymap.h.

References isKeyboard(), and keyModel.

Referenced by Kb::isKeyboard(), and isKeyboard().

{ return isKeyboard(keyModel); }

Here is the call graph for this function:

Here is the caller graph for this function:

static bool KeyMap::isMouse ( Model  model )

inlinestatic

Definition at line 95 of file keymap.h.

References M65, SABRE, and SCIMITAR.

Referenced by KbBind::isMouse(), KeyWidget::map(), KbLightWidget::newSelection(), and KeyWidget::paintEvent().

{ return model == M65 || model == SABRE || model == SCIMITAR; }

Here is the caller graph for this function:

bool KeyMap::isMouse ( ) const

inline

Definition at line 96 of file keymap.h.

References isMouse(), and keyModel.

Referenced by isKeyboard(), Kb::isMouse(), isMouse(), and KeyWidget::paintEvent().

{ return isMouse(keyModel); }

Here is the call graph for this function:

Here is the caller graph for this function:

Key KeyMap::key ( const QString &  name ) const

inline

Definition at line 125 of file keymap.h.

References _keys.

Referenced by AnimScript::begin(), byPosition(), AnimScript::keypress(), KbBind::noAction(), operator[](), KbBind::setAction(), and toStorage().

{ Key empty = {0,0,0,0,0,0,0,0,0}; return _keys.value(name, empty); }

Here is the caller graph for this function:

QStringList KeyMap::keys ( ) const

inline

Definition at line 131 of file keymap.h.

References _keys.

Referenced by KeyWidget::mouseReleaseEvent(), KbBindWidget::on_copyButton_clicked(), KbBindWidget::on_resetButton_clicked(), KeyWidget::setAnimation(), KeyWidget::setSelection(), and KbBindWidget::updateBind().

{ return _keys.keys(); }

Here is the caller graph for this function:

Layout KeyMap::layout ( ) const

inline

Definition at line 114 of file keymap.h.

References keyLayout.

Referenced by KeyAction::friendlyName(), KeyWidget::paintEvent(), and RebindWidget::setBind().

{ return keyLayout; }

Here is the caller graph for this function:

QStringList KeyMap::layoutNames ( )

static

Definition at line 479 of file keymap.cpp.

Referenced by LayoutDialog::LayoutDialog(), and SettingsWidget::SettingsWidget().

                               {
    return QStringList()
            << "Danish"
            << "English (ISO/European)" << "English (ISO/European, Dvorak)"
            << "English (United Kingdom)" << "English (United Kingdom, Dvorak)"
            << "English (United States)" << "English (United States, Dvorak)"
            << "French"
            << "German"
            << "Italian"
            << "Norwegian"
            << "Polish"
            << "Spanish (Latin America)"
            << "Spanish (Spain)"
            << "Swedish";
}

Here is the caller graph for this function:

KeyMap::Layout KeyMap::locale ( )

static

Definition at line 375 of file keymap.cpp.

References DE, DK, ES, FR, GB, IT, MX, NO, PL, SE, and US.

Referenced by SettingsWidget::SettingsWidget().

                           {
    setlocale(LC_ALL, "");
    QString loc = setlocale(LC_CTYPE, 0);
    loc = loc.toLower().replace('_', '-');
    if(loc.startsWith("dk-"))
        return KeyMap::DK;
    else if(loc.startsWith("fr-"))
        return KeyMap::FR;
    else if(loc.startsWith("de-"))
        return KeyMap::DE;
    else if(loc.startsWith("it-"))
        return KeyMap::IT;
    else if(loc.startsWith("pl-"))
        return KeyMap::PL;
    else if(loc.startsWith("no-"))
        return KeyMap::NO;
    else if(loc.startsWith("es-es"))
        // Spain uses the ES layout
        return KeyMap::ES;
    else if(loc.startsWith("es-"))
        // Other Spanish locales use MX
        return KeyMap::MX;
    else if(loc.startsWith("se-"))
        return KeyMap::SE;
    else if(loc.startsWith("en-us") || loc.startsWith("en-au") || loc.startsWith("en-ca") || loc.startsWith("en-hk") || loc.startsWith("en-in") || loc.startsWith("en-nz") || loc.startsWith("en-ph") || loc.startsWith("en-sg") || loc.startsWith("en-za"))
        // Most English locales use US
        return KeyMap::US;
    else
        // Default to GB
        return KeyMap::GB;
}

Here is the caller graph for this function:

const QHash<QString, Key>& KeyMap::map ( ) const

inline

Definition at line 129 of file keymap.h.

References _keys.

Referenced by friendlyName().

{ return _keys; }

Here is the caller graph for this function:

Model KeyMap::model ( ) const

inline

Definition at line 113 of file keymap.h.

References keyModel.

Referenced by KeyWidget::mouseMoveEvent(), KeyWidget::paintEvent(), and KPerfWidget::setPerf().

{ return keyModel; }

Here is the caller graph for this function:

int KeyMap::modelHeight ( Model  model )

staticprivate

Definition at line 561 of file keymap.cpp.

References K65, K70, K95, K95_HEIGHT, M65, M65_HEIGHT, SABRE, SCIMITAR, and STRAFE.

                                  {
    switch(model){
    case K65:
    case K70:
    case K95:
    case STRAFE:
        return K95_HEIGHT;
    case M65:
    case SABRE:
    case SCIMITAR:
        return M65_HEIGHT;
    default:
        return 0;
    }
}

int KeyMap::modelWidth ( Model  model )

staticprivate

Definition at line 542 of file keymap.cpp.

References K65, K65_WIDTH, K70, K70_WIDTH, K95, K95_WIDTH, KSTRAFE_WIDTH, M65, M65_WIDTH, SABRE, SCIMITAR, and STRAFE.

                                 {
    switch(model){
    case K65:
        return K65_WIDTH;
    case K70:
        return K70_WIDTH;
    case K95:
        return K95_WIDTH;
    case STRAFE:
        return KSTRAFE_WIDTH;
    case M65:
    case SABRE:
    case SCIMITAR:
        return M65_WIDTH;
    default:
        return 0;
    }
}

QString KeyMap::name ( ) const

inline

Definition at line 115 of file keymap.h.

References strLayout(), and strModel().

Referenced by KbBind::save(), KbLight::save(), and toStorage().

{ return (strModel() + " " + strLayout()).toUpper(); }

Here is the call graph for this function:

Here is the caller graph for this function:

KeyMap::operator const QHash< QString, Key > & ( ) const

inline

Definition at line 130 of file keymap.h.

References _keys.

{ return _keys; }

Key KeyMap::operator[] ( const QString &  name ) const

inline

Definition at line 126 of file keymap.h.

References key().

{ return key(name); }

Here is the call graph for this function:

QList<Key> KeyMap::positions ( ) const

inline

Definition at line 132 of file keymap.h.

References _keys.

Referenced by ColorMap::init(), and KeyWidget::selectAll().

{ return _keys.values(); }

Here is the caller graph for this function:

QString KeyMap::strLayout ( ) const

inline

Definition at line 106 of file keymap.h.

References getLayout(), and keyLayout.

Referenced by name().

{ return getLayout(keyLayout); }

Here is the call graph for this function:

Here is the caller graph for this function:

QString KeyMap::strModel ( ) const

inline

Definition at line 110 of file keymap.h.

References getModel(), and keyModel.

Referenced by name().

{ return getModel(keyModel); }

Here is the call graph for this function:

Here is the caller graph for this function:

QString KeyMap::toStorage ( const QString &  name )

inline

Definition at line 134 of file keymap.h.

References key(), name(), and Key::storageName().

{ const char* storage = key(name).storageName(); if(!storage) return name; return storage; }

Here is the call graph for this function:

uint KeyMap::width ( ) const

inline

Definition at line 120 of file keymap.h.

References keyWidth.

Referenced by KeyWidget::drawInfo(), and KeyWidget::map().

{ return keyWidth; }

Here is the caller graph for this function:

Field Documentation

QHash<QString, Key> KeyMap::_keys

private

Definition at line 147 of file keymap.h.

Referenced by contains(), count(), key(), keys(), map(), operator const QHash< QString, Key > &(), and positions().

short KeyMap::keyHeight

private

Definition at line 148 of file keymap.h.

Referenced by height().

Layout KeyMap::keyLayout

private

Definition at line 150 of file keymap.h.

Referenced by isISO(), layout(), and strLayout().

Model KeyMap::keyModel

private

Definition at line 149 of file keymap.h.

Referenced by isKeyboard(), isMouse(), model(), and strModel().

short KeyMap::keyWidth

private

Definition at line 148 of file keymap.h.

Referenced by width().

---

The documentation for this class was generated from the following files:

• src/ckb/keymap.h
• src/ckb/keymap.cpp
