KbBind Class Reference

#include <src/ckb/kbbind.h>

Inheritance diagram for KbBind:

Collaboration diagram for KbBind:

Public Slots
void	keyEvent (const QString &key, bool down)

Signals
void	didLoad ()
void	layoutChanged ()
void	updated ()

Public Member Functions
	KbBind (KbMode *modeParent, Kb *devParent, const KeyMap &keyMap)
	KbBind (KbMode *modeParent, Kb *devParent, const KeyMap &keyMap, const KbBind &other)
	KbBind. More...
void	load (CkbSettings &settings)
void	save (CkbSettings &settings)
bool	needsSave () const
const KeyMap &	map ()
void	map (const KeyMap &map)
bool	isISO () const
bool	isKeyboard () const
bool	isMouse () const
KbPerf *	perf ()
KbLight *	light ()
QString	action (const QString &key)
QString	friendlyName (const QString &key)
QString	friendlyActionName (const QString &key)
void	setAction (const QString &key, const QString &action)
void	setAction (const QStringList &keys, const QString &action)
void	resetAction (const QString &key)
void	resetAction (const QStringList &keys)
void	noAction (const QString &key)
void	noAction (const QStringList &keys)
bool	winLock ()
void	winLock (bool newWinLock)
void	update (QFile &cmd, bool force=false)
void	setNeedsUpdate ()
int	getMacroNumber ()
	KbBind::getMacroNumber. More...
QString	getMacroPath ()
	KbBind::getMacroPath. More...
void	handleNotificationChannel (bool start)
	handleNotificationChannel sends commands to ckb-daemon for (de-) activating the notify channel. Send a notify cmd to the keyboard to set or clear notification for reading macro definition. The file handle for the cmd pipe is stored in lastCmd. More...

Static Public Member Functions
static QString	globalRemap (const QString &key)
static void	setGlobalRemap (const QHash< QString, QString > keyToActual)
static void	loadGlobalRemap ()
static void	saveGlobalRemap ()
static QString	defaultAction (const QString &key)

Private Member Functions
Kb *	devParent () const
KbMode *	modeParent () const
KeyAction *	bindAction (const QString &key)

Private Attributes
Kb *	_devParent
quint64	lastGlobalRemapTime
QFile *	lastCmd
	lastCmd is a cache-hack. Because the QFile ist opened in Kb, and we need it in the macro processing functions, we cache the value her in lastCmd. More...
KeyMap	_map
QHash< QString, KeyAction * >	_bind
bool	_winLock
bool	_needsUpdate
bool	_needsSave

Static Private Attributes
static QHash< QString, QString >	_globalRemap
static quint64	globalRemapTime = 0

Friends
class	KeyAction

Detailed Description

Definition at line 20 of file kbbind.h.

Constructor & Destructor Documentation

KbBind::KbBind ( KbMode *  modeParent, Kb *  devParent, const KeyMap &  keyMap  )

explicit

Definition at line 12 of file kbbind.cpp.

                                                                        :
    QObject(modeParent), _devParent(parentBoard), lastGlobalRemapTime(globalRemapTime), _map(keyMap),
    _winLock(false), _needsUpdate(true), _needsSave(true) {
}

KbBind::KbBind	(	KbMode *	modeParent,
		Kb *	parentBoard,
		const KeyMap &	keyMap,
		const KbBind &	other
	)

KbBind::KbBind // copy all existing Key bindings.

Parameters

modeParent
devParent
keyMap
other	This is the KbBind object to copy from Use this constructor to copy an existing Binding
modeParent
parentBoard
keyMap
other

Create a new Hash table and copy all entries

clear the destination list (there are the original KeyActions as references, so do not delete them)

and move the KeyActions we just created

Definition at line 24 of file kbbind.cpp.

References _bind, KeyAction, map(), and KeyAction::value().

                                                                                             :
    QObject(modeParent), _devParent(parentBoard), lastGlobalRemapTime(globalRemapTime), _bind(other._bind),
    _winLock(false), _needsUpdate(true), _needsSave(true) {
    map(keyMap);

    QHash<QString, KeyAction*> newBind;
    foreach(QString key, _bind.keys()) {
        KeyAction* act = _bind.value(key);
        if(act) {
            newBind[key] = new KeyAction(act->value(), this);
        }
    }

    _bind.clear();
    foreach(QString key, newBind.keys()) {
        KeyAction* act = newBind.value(key);
        if(act) {
            _bind[key] = new KeyAction(act->value(), this);
        }
    }
    newBind.clear();      // here we *must not* delete the KeyActions, because they are referenced by _bind now
}

Here is the call graph for this function:

Member Function Documentation

QString KbBind::action

(

const QString &

key

)

Definition at line 140 of file kbbind.cpp.

References bindAction(), globalRemap(), and KeyAction::value().

Referenced by friendlyActionName(), KbBindWidget::on_copyButton_clicked(), resetAction(), RebindWidget::setSelection(), and KbBindWidget::updateBind().

                                        {
    QString rKey = globalRemap(key);
    return bindAction(rKey)->value();
}

Here is the call graph for this function:

Here is the caller graph for this function:

KeyAction* KbBind::bindAction ( const QString &  key )

inlineprivate

Definition at line 117 of file kbbind.h.

References _bind, KeyAction::defaultAction(), and KeyAction.

Referenced by action(), keyEvent(), and update().

{ if(!_bind.contains(key)) return _bind[key] = new KeyAction(KeyAction::defaultAction(key), this); return _bind[key]; }

Here is the call graph for this function:

Here is the caller graph for this function:

QString KbBind::defaultAction ( const QString &  key )

static

Definition at line 145 of file kbbind.cpp.

References KeyAction::defaultAction(), and globalRemap().

Referenced by KeyWidget::paintEvent(), and RebindWidget::setBind().

                                               {
    QString rKey = globalRemap(key);
    return KeyAction::defaultAction(rKey);
}

Here is the call graph for this function:

Here is the caller graph for this function:

Kb* KbBind::devParent ( ) const

inlineprivate

Definition at line 114 of file kbbind.h.

References _devParent.

Referenced by getMacroNumber(), getMacroPath(), and KeyAction::keyEvent().

{ return _devParent; }

Here is the caller graph for this function:

void KbBind::didLoad ( )

signal

Definition at line 155 of file moc_kbbind.cpp.

Referenced by load().

{
    QMetaObject::activate(this, &staticMetaObject, 0, Q_NULLPTR);
}

Here is the caller graph for this function:

QString KbBind::friendlyActionName

(

const QString &

key

)

Definition at line 157 of file kbbind.cpp.

References _map, action(), and KeyAction.

Referenced by KbBindWidget::updateSelDisplay().

                                                    {
    QString act = action(key);
    return KeyAction(act).friendlyName(_map);
}

Here is the call graph for this function:

Here is the caller graph for this function:

QString KbBind::friendlyName

(

const QString &

key

)

Definition at line 150 of file kbbind.cpp.

References _map, Key::friendlyName(), and globalRemap().

                                              {
    const Key& pos = _map[globalRemap(key)];
    if(!pos)
        return "(Unknown)";
    return pos.friendlyName();
}

Here is the call graph for this function:

int KbBind::getMacroNumber

(

)

Returns

number of notification channel. Use it in combination with notifyon/off-Statement

Definition at line 257 of file kbbind.cpp.

References devParent(), and Kb::getMacroNumber().

Referenced by handleNotificationChannel(), and RebindWidget::on_btnStartMacro_clicked().

                           {
    return devParent()->getMacroNumber();
}

Here is the call graph for this function:

Here is the caller graph for this function:

QString KbBind::getMacroPath

(

)

Returns

Filepath of macro notification pipe. If not set, returns initial value ""

Definition at line 265 of file kbbind.cpp.

References devParent(), and Kb::getMacroPath().

Referenced by RebindWidget::on_btnStartMacro_clicked().

                             {
    return devParent()->getMacroPath();
}

Here is the call graph for this function:

Here is the caller graph for this function:

QString KbBind::globalRemap ( const QString &  key )

static

Definition at line 98 of file kbbind.cpp.

References _globalRemap.

Referenced by action(), defaultAction(), friendlyName(), keyEvent(), noAction(), KeyWidget::paintEvent(), resetAction(), setAction(), and SettingsWidget::SettingsWidget().

                                             {
    if(!_globalRemap.contains(key))
        return key;
    return _globalRemap.value(key);
}

Here is the caller graph for this function:

void KbBind::handleNotificationChannel

(

bool

start

)

Parameters

start	is boolean. If true, notification channel is opened for all keys, otherwise channel ist closed.
start	If true, notification channel is opened for all keys, otherwise channel ist closed.

Definition at line 275 of file kbbind.cpp.

References getMacroNumber(), and lastCmd.

Referenced by RebindWidget::on_btnStartMacro_clicked(), and RebindWidget::on_btnStopMacro_clicked().

                                                 {
    if (getMacroNumber() > 0 && lastCmd) {
        if (start) {
            lastCmd->write (QString("\nnotifyon %1\n@%1 notify all:on\n").arg(getMacroNumber()).toLatin1());
        } else {
            lastCmd->write (QString("\n@%1 notify all:off\nnotifyoff %1\n").arg(getMacroNumber()).toLatin1());
        }
        lastCmd->flush();
    } else qDebug() << QString("No cmd or valid handle for notification found, macroNumber = %1, lastCmd = %2")
                       .arg(getMacroNumber()).arg(lastCmd? "set" : "unset");
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool KbBind::isISO ( ) const

inline

Definition at line 43 of file kbbind.h.

References _map, and KeyMap::isISO().

{ return _map.isISO(); }

Here is the call graph for this function:

bool KbBind::isKeyboard ( ) const

inline

Definition at line 44 of file kbbind.h.

References _map, and KeyMap::isKeyboard().

{ return _map.isKeyboard(); }

Here is the call graph for this function:

bool KbBind::isMouse ( ) const

inline

Definition at line 45 of file kbbind.h.

References _map, and KeyMap::isMouse().

Referenced by KbBindWidget::on_copyButton_clicked(), KbBindWidget::on_resetButton_clicked(), RebindWidget::setBind(), and KbBindWidget::updateSelDisplay().

{ return _map.isMouse(); }

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::keyEvent ( const QString &  key, bool  down  )

slot

Definition at line 287 of file kbbind.cpp.

References bindAction(), globalRemap(), and KeyAction::keyEvent().

Referenced by Kb::readNotify().

                                                  {
    QString rKey = globalRemap(key);
    KeyAction* act = bindAction(rKey);
    if(act)
        act->keyEvent(this, down);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::layoutChanged ( )

signal

Definition at line 161 of file moc_kbbind.cpp.

Referenced by map().

{
    QMetaObject::activate(this, &staticMetaObject, 1, Q_NULLPTR);
}

Here is the caller graph for this function:

KbLight * KbBind::light

(

)

Definition at line 54 of file kbbind.cpp.

References KbMode::light(), and modeParent().

Referenced by RebindWidget::applyChanges(), KeyAction::keyEvent(), and RebindWidget::setSelection().

                      {
    return modeParent()->light();
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::load

(

CkbSettings &

settings

)

Definition at line 58 of file kbbind.cpp.

References _bind, _map, _needsSave, _winLock, CkbSettings::childKeys(), didLoad(), KeyMap::fromName(), KeyMap::fromStorage(), KeyAction, map(), and CkbSettings::value().

Referenced by KbMode::KbMode().

                                      {
    _needsSave = false;
    SGroup group(settings, "Binding");
    KeyMap currentMap = _map;
    _map = KeyMap::fromName(settings.value("KeyMap").toString());
    // Load key settings
    bool useReal = settings.value("UseRealNames").toBool();
    _bind.clear();
    {
        SGroup group(settings, "Keys");
        foreach(QString key, settings.childKeys()){
            QString name = key.toLower();
            if(!useReal)
                name = _map.fromStorage(name);
            QString bind = settings.value(key).toString();
            _bind[name] = new KeyAction(bind, this);
        }
    }
    _winLock = settings.value("WinLock").toBool();
    emit didLoad();
    map(currentMap);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::loadGlobalRemap ( )

static

Definition at line 116 of file kbbind.cpp.

References _globalRemap, CkbSettings::childKeys(), globalRemapTime, and CkbSettings::value().

Referenced by SettingsWidget::SettingsWidget().

                            {
    _globalRemap.clear();
    CkbSettings settings("Program/GlobalRemap");
    foreach(const QString& key, settings.childKeys())
        _globalRemap[key] = settings.value(key).toString();
    globalRemapTime = QDateTime::currentMSecsSinceEpoch();
}

Here is the call graph for this function:

Here is the caller graph for this function:

const KeyMap& KbBind::map ( )

inline

Definition at line 41 of file kbbind.h.

References _map.

Referenced by KbBind(), KbMode::keyMap(), load(), map(), KbBindWidget::newLayout(), KbBindWidget::on_copyButton_clicked(), KbBindWidget::on_resetButton_clicked(), RebindWidget::setBind(), KbBindWidget::updateBind(), and KbBindWidget::updateSelDisplay().

{ return _map; }

Here is the caller graph for this function:

void KbBind::map

(

const KeyMap &

map

)

Definition at line 133 of file kbbind.cpp.

References _map, _needsSave, _needsUpdate, layoutChanged(), and map().

                                 {
    _map = map;
    _needsUpdate = true;
    _needsSave = true;
    emit layoutChanged();
}

Here is the call graph for this function:

KbMode* KbBind::modeParent ( ) const

inlineprivate

Definition at line 115 of file kbbind.h.

Referenced by light(), and perf().

{ return (KbMode*)parent(); }

Here is the caller graph for this function:

bool KbBind::needsSave ( ) const

inline

Definition at line 38 of file kbbind.h.

References _needsSave.

Referenced by KbMode::needsSave().

{ return _needsSave; }

Here is the caller graph for this function:

void KbBind::noAction

(

const QString &

key

)

Definition at line 172 of file kbbind.cpp.

References _bind, _map, globalRemap(), KeyMap::key(), KeyAction, and resetAction().

Referenced by RebindWidget::applyChanges(), and RebindWidget::on_unbindButton_clicked().

                                       {
    resetAction(key);
    QString rKey = globalRemap(key);
    if(!_map.key(rKey))
        return;
    _bind[rKey] = new KeyAction(this);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::noAction ( const QStringList &  keys )

inline

Definition at line 75 of file kbbind.h.

References noAction().

Referenced by noAction().

{ foreach(const QString& key, keys) noAction(key); }

Here is the call graph for this function:

Here is the caller graph for this function:

KbPerf * KbBind::perf

(

)

Definition at line 50 of file kbbind.cpp.

References modeParent(), and KbMode::perf().

Referenced by KeyAction::keyEvent(), and RebindWidget::setBind().

                    {
    return modeParent()->perf();
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::resetAction

(

const QString &

key

)

Definition at line 162 of file kbbind.cpp.

References _bind, _needsSave, _needsUpdate, action(), and globalRemap().

Referenced by noAction(), KbBindWidget::on_resetButton_clicked(), RebindWidget::on_resetButton_clicked(), and setAction().

                                          {
    QString rKey = globalRemap(key);
    // Clean up existing action (if any)
    KeyAction* action = _bind.value(rKey);
    delete action;
    _bind.remove(rKey);
    _needsUpdate = true;
    _needsSave = true;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::resetAction ( const QStringList &  keys )

inline

Definition at line 72 of file kbbind.h.

References resetAction().

Referenced by resetAction().

{ foreach(const QString& key, keys) resetAction(key); }

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::save

(

CkbSettings &

settings

)

Definition at line 81 of file kbbind.cpp.

References _bind, _map, _needsSave, _winLock, KeyAction::defaultAction(), KeyMap::name(), CkbSettings::setValue(), and KeyAction::value().

Referenced by KbMode::save().

                                      {
    _needsSave = false;
    SGroup group(settings, "Binding");
    settings.setValue("KeyMap", _map.name());
    // Save key settings
    settings.setValue("UseRealNames", true);
    {
        SGroup group(settings, "Keys");
        foreach(QString key, _bind.keys()){
            KeyAction* act = _bind.value(key);
            if(act && act->value() != KeyAction::defaultAction(key))
                settings.setValue(key, act->value());
        }
    }
    settings.setValue("WinLock", _winLock);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::saveGlobalRemap ( )

static

Definition at line 124 of file kbbind.cpp.

References _globalRemap, and CkbSettings::setValue().

Referenced by SettingsWidget::updateModifiers().

                            {
    CkbSettings settings("Program/GlobalRemap", true);
    QHashIterator<QString, QString> i(_globalRemap);
    while(i.hasNext()){
        i.next();
        settings.setValue(i.key(), i.value());
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::setAction	(	const QString &	key,
		const QString &	action
	)

Definition at line 180 of file kbbind.cpp.

References _bind, _map, globalRemap(), KeyMap::key(), KeyAction, and resetAction().

Referenced by RebindWidget::applyChanges(), and KbBindWidget::on_copyButton_clicked().

                                                               {
    resetAction(key);
    QString rKey = globalRemap(key);
    if(!_map.key(rKey))
        return;
    _bind[rKey] = new KeyAction(action, this);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::setAction ( const QStringList &  keys, const QString &  action  )

inline

Definition at line 69 of file kbbind.h.

References setAction().

Referenced by setAction().

{ foreach(const QString& key, keys) setAction(key, action); }

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::setGlobalRemap ( const QHash< QString, QString >  keyToActual )

static

Definition at line 104 of file kbbind.cpp.

References _globalRemap, and globalRemapTime.

Referenced by SettingsWidget::updateModifiers().

                                                                    {
    _globalRemap.clear();
    // Ignore any keys with the standard binding
    QHashIterator<QString, QString> i(keyToActual);
    while(i.hasNext()){
        i.next();
        if(i.key() != i.value())
            _globalRemap[i.key()] = i.value();
    }
    globalRemapTime = QDateTime::currentMSecsSinceEpoch();
}

Here is the caller graph for this function:

void KbBind::setNeedsUpdate ( )

inline

Definition at line 84 of file kbbind.h.

References _needsUpdate.

Referenced by KbMode::setNeedsUpdate().

{ _needsUpdate = true; }

Here is the caller graph for this function:

void KbBind::update	(	QFile &	cmd,
		bool	force = false
	)

Definition at line 188 of file kbbind.cpp.

References _bind, _globalRemap, _needsUpdate, _winLock, bindAction(), KeyAction::driverName(), globalRemapTime, KeyAction::isValidMacro(), lastCmd, lastGlobalRemapTime, KeyAction::macroContent(), updated(), and KeyAction::value().

Referenced by Kb::frameUpdate().

                                         {
    if(!force && !_needsUpdate && lastGlobalRemapTime == globalRemapTime)
        return;
    lastGlobalRemapTime = globalRemapTime;
    emit updated();
    _needsUpdate = false;
    // Reset all keys and enable notifications for all
    cmd.write("rebind all notify all");
    // Make sure modifier keys are included as they may be remapped globally
    QHash<QString, KeyAction*> bind(_bind);
    if(!_bind.contains("caps")) bind["caps"] = 0;
    if(!_bind.contains("lshift")) bind["lshift"] = 0;
    if(!_bind.contains("rshift")) bind["rshift"] = 0;
    if(!_bind.contains("lctrl")) bind["lctrl"] = 0;
    if(!_bind.contains("rctrl")) bind["rctrl"] = 0;
    if(!_bind.contains("lwin")) bind["lwin"] = 0;
    if(!_bind.contains("rwin")) bind["rwin"] = 0;
    if(!_bind.contains("lalt")) bind["lalt"] = 0;
    if(!_bind.contains("ralt")) bind["ralt"] = 0;
    if(!_bind.contains("fn")) bind["fn"] = 0;
    QHashIterator<QString, KeyAction*> i(bind);

    // Initialize String buffer for macro Key definitions (G-keys)
    // "macro clear" is neccessary, if an older definition is unbound.
    QString macros = "\nmacro clear\n";

    // Write out rebound keys and collect infos for macro definitions
    while(i.hasNext()){
        i.next();
        QString key = i.key();
        KeyAction* act = i.value();
        if(_globalRemap.contains(key))
            act = bindAction(_globalRemap.value(key));
        if(!act)
            continue;
        QString value = act->driverName();
        if(value.isEmpty()){
            // If the key is unbound or is a special action, unbind it
            cmd.write(" unbind ");
            cmd.write(key.toLatin1());
            // if a macro definiton for the key is given,
            // add the converted string to key-buffer "macro"
            if (act->isValidMacro()) {
                if (act->macroContent().length() > 0) {
                    macros.append("macro " + key.toLatin1() + ":" + act->macroContent().toLatin1() + "\n");
                }
            }
        } else {
            // Otherwise, write the binding
            cmd.write(" bind ");
            cmd.write(key.toLatin1());
            cmd.write(":");
            cmd.write(value.toLatin1());
        }
    }
    // If win lock is enabled, unbind windows keys
    if(_winLock)
        cmd.write(" unbind lwin rwin");

    // At last, send Macro definitions if available.
    // If no definitions are made, clear macro will be sent only to reset all macros,
    cmd.write(macros.toLatin1());
    lastCmd = &cmd;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void KbBind::updated ( )

signal

Definition at line 167 of file moc_kbbind.cpp.

Referenced by update().

{
    QMetaObject::activate(this, &staticMetaObject, 2, Q_NULLPTR);
}

Here is the caller graph for this function:

bool KbBind::winLock ( )

inline

Definition at line 78 of file kbbind.h.

References _winLock.

Referenced by KeyAction::keyEvent().

{ return _winLock; }

Here is the caller graph for this function:

void KbBind::winLock ( bool  newWinLock )

inline

Definition at line 79 of file kbbind.h.

References _needsUpdate, and _winLock.

{ _winLock = newWinLock; _needsUpdate = true; }

Friends And Related Function Documentation

friend class KeyAction

friend

Definition at line 136 of file kbbind.h.

Referenced by bindAction(), friendlyActionName(), KbBind(), load(), noAction(), and setAction().

Field Documentation

QHash<QString, KeyAction*> KbBind::_bind

private

Definition at line 131 of file kbbind.h.

Referenced by bindAction(), KbBind(), load(), noAction(), resetAction(), save(), setAction(), and update().

Kb* KbBind::_devParent

private

Definition at line 113 of file kbbind.h.

Referenced by devParent().

QHash< QString, QString > KbBind::_globalRemap

staticprivate

Definition at line 119 of file kbbind.h.

Referenced by globalRemap(), loadGlobalRemap(), saveGlobalRemap(), setGlobalRemap(), and update().

KeyMap KbBind::_map

private

Definition at line 129 of file kbbind.h.

Referenced by friendlyActionName(), friendlyName(), isISO(), isKeyboard(), isMouse(), load(), map(), noAction(), save(), and setAction().

bool KbBind::_needsSave

private

Definition at line 135 of file kbbind.h.

Referenced by load(), map(), needsSave(), resetAction(), and save().

bool KbBind::_needsUpdate

private

Definition at line 134 of file kbbind.h.

Referenced by map(), resetAction(), setNeedsUpdate(), update(), and winLock().

bool KbBind::_winLock

private

Definition at line 133 of file kbbind.h.

Referenced by load(), save(), update(), and winLock().

quint64 KbBind::globalRemapTime = 0

staticprivate

Definition at line 120 of file kbbind.h.

Referenced by loadGlobalRemap(), setGlobalRemap(), and update().

QFile* KbBind::lastCmd

private

Definition at line 127 of file kbbind.h.

Referenced by handleNotificationChannel(), and update().

quint64 KbBind::lastGlobalRemapTime

private

Definition at line 121 of file kbbind.h.

Referenced by update().

---

The documentation for this class was generated from the following files:

• src/ckb/kbbind.h
• src/ckb/kbbind.cpp
• src/ckb/release/moc_kbbind.cpp
